About: Apantac Mi-16 Low latency 16x1 Video Multiviewer

Apantac Mi-16 Low latency 16x1 Video Multiviewer in a rack and offering HD, SD SDI video inputs, auto detect, with passive input loops. Two sets of HDMI (1080P 50/60Hz) and SDI (1080i/P 50/60Hz) Outputs. Windows can have multiple sizes and can be moved freely. UMDs, OMDs and standalone labels. Analog, Digital Clocks/Counters and Logos. 32 GPI for tally/presets. Supports the TSL protocol over IP and serial. 30 internal presets.

Features

Low latency - single frame processing delay
Accepts 16 auto-detect 3G/HD/SD-SDI inputs
16 Passive input loop through
Windows can be sized and moved freely
Decode up to 16 embedded audio per SDI input
2 simultaneous and identical HDMI and SDI outputs
Ethernet for configuration and external control
Dynamic UMD/labels & Tallies (TSL)
Stand alone labels, customizable logos
32 GPIs for tallies, count up/down triggers or alarms
2 digital and 2 analog clocks can be sync’d with LTC or NTP
Borders can be turned on or off
Safe area markers
Visual Alarm tags for video/audio alarm detection
Audio monitoring output - Stereo, AES, Embedded SDI and HDMI
Optional redundant power supply
3 year limited warranty
