About: Avitech Pacific MS-3C 20x16 Matrix For HDMI SDI USB Switching

Avitech Pacific MS-3C Designed for streamlined operation for a cluster of users with multiple systems, Pacific MS-3C allows creation of multi-screen multiview user space by grouping display outputs. The “Surfer” feature allows user to manage a variety of systems across multiple monitors and seamlessly switch control to any of the system via one set of mouse and keyboard.

Employing output cards with dual scalers, the Pacific MS-3C delivers an affordable solution to seamlessly switch/route any video signal across numerous displays. Multiple sets of sources can also be seamlessly routed to respective destinations all at once with a single command, fully addressing the needs for uninterrupted image or video transitions throughout staging and presentation applications.

Features

Three RU chassis providing 20x16 matrix for HDMI, SDI, and USB switching, monitoring, and control.
Rack chassis with control board and front button panel.
Control board with in-system GUI for making source switching, preview, and local system KVM connection.
Built-in HDBaseT port extents GUI/local system KVM to 100-meter.
HDBaseT receiver is optional, sold separately.
Provide card slot for 5 input cards, 4 output cards, and 3 USB/KM cards.
One external 12V DC 252Watt power adapter.

Model: Pacific MS-3C

Avitech Pacific MS-3C 20x16 Matrix For HDMI SDI USB Switching

Brands Avitech
Product Code:Pacific MS-3C
Availability:In Stock
